It can be used in industries such as medicine, proteins, microorganisms, soil, and food.
PID control based on adaptive algorithm：By incorporating adaptive algorithms into the classic PID control, the device control can become more precise and less affected by environmental conditions and fluctuations in device performance.
Eutectic point test: The eutectic point of the sample is an important indicator for the freeze-drying process.
Dual sensor -- determination of freeze drying endpoint: Optional capacitive sensors can be used. By comparing the measurement values obtained from two different measurement principles of vacuum sensors, the freeze-drying endpoint can be determined.
Ergonomic design：The equipment is simple and elegant, occupying little space. It enables comfortable operation of the instrument. The height, angle and layout of the instrument are adapted to the user's height, thereby enhancing work efciency and reducing fatigue. The design of the operation interface and buttons is simple and intuitive, making it easy to understand and operate.
|
Technical Specifcation |
LYO 0885D |
||
|
Can save 30 protocol, each with 36 ramps |
● |
Cold trap temperature |
-85℃ |
|
Computer software |
● |
Shelf temperature |
-55~60℃ |
|
Defrosting |
Hos gas defrosting |
Shelf Qty. |
3+1 |
|
Hydraulic stoppering device |
● |
Shelf spacing |
80mm |
|
Pressure rise test |
● |
Shelf area |
0.3 m² |
|
Safety pressure |
● |
Shelf dimension |
240*410mm |
|
Safety resistance |
● |
Ice efciency |
6Kg/24h |
|
Sample/shelf/actual temperature testing |
● |
Ice capacity |
8Kg |
|
Eutectic point testing |
● |
Shelf temperature precision |
±1℃ |
|
Online infation |
● |
Dimension |
W960*D765*H1320mm |
|
Capacitive vacuum sensor |
○ |
Weight |
330Kg |
|
Instantaneous nucleation |
○ |
Power |
2.9Kg |
|
USB interface |
● |
Power requirements |
16A,220V |
