Concenfuge IR1000 Series Fully Automated Solvent Workstation delivers superior performance, broader application versatility, and a more user-friendly operation. It enables rapid, simple, safe, and eco-friendly removal of most common solvents and acids.
Operating Principle
-
The system creates a vacuum environment using a vacuum pump, significantly lowering the boiling point of solvents.
-
High-speed centrifugation effectively prevents sample loss due to bumping during evaporation while minimizing foam formation.
-
A heating element accelerates evaporation, while a cold trap condenses solvent vapors, protecting the vacuum pump and improving concentration efficiency.
-
Samples processed by centrifugal concentration are ready for various qualitative and quantitative analyses-including chemical, biochemical, bioanalytical, immunoassay, and food safety residue testing.
Product Adavantages
-
The innovative infrared heating technology significantly accelerates concentration speed.
-
Lowest loss rate with horizontal swing rotor.
-
Explosion-proof design for safe handling of flammable/volatile solvents.
-
Non-contact sample measurement and experimental process control can be performed with clear visibility.
-
Intelligent evaporation software system for precision & efficiency.
-
Compatible with a wide range of high-boiling-point solvents.
Product Features
-
Integrated design: integrated centrifugal heating chamber, condenser, cold trap, operating system, etc., compact structure, reduced space occupation, applicable solvent boiling point up to 220°C, meet the needs of DMSO, alcohols, ethyl acetate, acetonitrile, water, TFA and other solvents;
-
Vacuum control range: 0.1mbar-1000mbar;
-
Anti-boiling technology: avoid cross contamination and sample loss caused by boiling. Inert gas protection device, safe concentration of explosive solvents such as ether and pentane;
-
Heating method: use high-power, long-life intrared lamp for heating;
-
With exhaust gas emptying function to protect the safety of experimenters;
-
Self-cleaning function: clean the residual solvent in the centrifugal chamber and pipeline to prevent cross contamination;
-
Horizontal rotor design can place various glass test tubes, centrifuge tubes, GC vials, round-bottom flasks, flash bottles, 60ml ASE tubes, 96-well plates, etc.
Technical Parameters
|
Technical Parameters
|
Concenfuge IR1000
|
Concenfuge IR1200
|
|
Speed range
|
800rpm~2000rpm
|
800rpm~2000rpm
|
|
Vacuum control range
|
0.1mbar~1000mbar
|
0.1mbar~1000mbar
|
|
Temperature control range
|
RT-70℃
|
RT-80℃
|
|
Ultimate vacuum
|
≤0.2mbar
|
≤0.2mbar
|
|
Self-cleaning function
|
Y
|
Y
|
|
Gradient vacuum function
|
Y
|
Y
|
|
Self-programming
|
Y
|
Y
|
|
Preheating function
|
Y
|
Y
|
|
Built-in cold trap temperature
|
-45℃
|
-50℃
|
|
Nitrogen purge
|
-
|
Y
|
|
Rapid freeze drying
|
-
|
Y
|
|
Noise
|
≤60dB(A)
|
≤60dB(A)
|
|
Power
|
1300W
|
1500W
|
|
Dimension(L×D×H)
|
635×446×510mm
|
635×446×510mm
|
